Troubleshooting
89
Applicutter
Err 8 The magnet or the sensor for
the loading arm is defect or
wrongly positioned
> Adjust the magnet/sensor
so, that the sensor is activat-
ed when the loading arm is in
correct position
•
Err 9 The maximum time between
two pulses of the film end stop
sensor is exceeded
> Check if the film end stop
sensor works
> Increase t14
•
•
65
Err 99 The activated function is not
available for this machine
off • The control panel does not
communicate with the driver
module
• Defect fuse at the main print
card in the driver module
> Check that the power supply
and the cables between con-
trol panel and driver module
are OK and properly con-
nected.
> Disconnect the power supply
for 15 sec and reconnect
> Check the fuse
Problem Cause Solution Page
Problem Cause Solution Page
The catch rod is not fully
charged
The applicutter is not adjusted
correctly
> Adjust the catch rod
The catch rod is not released Basic setting of the applicutter > Check that the distance be-
tween retainer and pawl is 10
- 20 mm
> Adjust correctly
The film is not cut • Too much pressure on the
roller
• Roller does not rotate freely
• The knife is dull
> Adjust the distance between
the roller and the retainer to
4 - 5 mm
> Oil the roller
> Exchange and adjust the
knife
