38
Preparation for use
Support rollers
To ensure a good stability of the bale during wrapping, the support roll-
ers can be adjusted for small or large bales.
Support rollers ad-
justment
The support roller must be adjusted so, that the bale is in the middle
of the table. When the bale is on the table, the clearance C on both
sides between the bale and both support rollers should be maximum
150 mm.
The support rollers can be placed in three positions. The middle or the
right hole are recommended.
> Remove the linch pin
> Place the roller in the correct hole, to adjust to clearance C
> Place the linch pin
C C
Support rollers
Support roller
Holes Linch pin
