Hitching the machine
29
Moving the drawbar
> Secure the drawbar by placing it in a well suited hoist
> Loosen the bolts and nuts
> Move the drawbar to the desired position
The drawbar must always be fitted with 3 bolts and nuts per side.
> Tighten the bolts and nuts
> Torque the bolts and nuts to 220 Nm
> Remove the hoist
Hitching
> Hitch and secure the machine to the towing hook of the tractor
36
69
Towing hook height (cm) Cm
Minimum 36
Maximum 69
BoltsNuts
Drawbar
