Changing procedure of the frame
1-11
1
In case of TEJTII-C/TEMX-C...................................................................
1.
Loosen the screw (5).
2.
Fix the hook cover (6) using the screw (5).
4. Check if the frame moves smoothly.
Check if the slide angle (1) moves smoothly to crosswise direction by hand. When
it does not move smoothly, check abrasion of the contact point (3) between the cap
frame base (2) and slide angle (1) and/or the slide plate (4).
Proceed to the next work.
It is not necessary to remove the attached hook cover (6)
even when frame spec. is changed. However, if the cap
frame guide has a disadvantage for embroidery work,
detach the hook cover (6).
CAUTION
Usage with load could cause damage of the
device and/or defective products.
Turn ON the power switch, or release sleep mode (p.1-19) and after
LX03
To Next Page
