TAJIMA TEMX-C - From Cap Frame to Tubular Goods Frame

1-14
Changing procedure of the frame
From cap frame to tubular goods frame
1.
Detaching of cap frame unit
1. Loosen the screws (1) and (2) to detach the cap frame unit (3).
2. Attaching of tubular goods frame sash
1. Fix the tubular goods frame sash (1) using the attaching screw (2).
3
1
2
1
2
1
2
KY01
