TAJIMA TEMX-C - From Tubular Goods Frame to Border Frame

1-12
Changing procedure of the frame
From tubular goods frame to border frame
1.
Detaching of tubular goods frame sash
1. Loosen the screw (2) to detach the tubular goods frame sash (1).
2. Switching of table position
In case of TFMX-C ..................................................................................
1. Pull the table (1) to the front to take out, and attach the table to the position of border
frame spec. (A).
In case of TEJTII-C/TEMX-C ..................................................................
1. Push the table (4) into the position and fix it using the screw (5).
1
2
1
2
Push the table (1) into the position and fix it using the
table spring (2) and table stopper (3).
23
1
A
Insert the table fitting (6) to the entry of the cover.
4
5
6
