TAJIMA TEMX-C - Cap Frame Setup

2-2
Set the frame.
1.Cap frame
[Setting procedure]
1. Set the cap frame (1) to the setting frame (2).
Push into the cap frame (1) until it is fixed by the lock pin (3) of the setting frame (2).
2. Set the interlining cloth (5) to the cap frame (1).
In case of semi-wide cap frame, although the
shape is different, the same manner is applied to
the working.
2
3
4
1
1
5
KY01
