Set the frame.
2-3
2
3. Pull the sweat band (6) of cap outside.
4. Perform setting so that the sweat band (6) is clipped between the bracket (7) and interlining cloth (5).
Align the center of cap with the mark-off line of the bracket (7) so that the visor (8) of cap comes directly above.
5. After positioning the cap, close the lid frame (9) and fix the cap using the lock (10).
6
7
5
8
6
7
6
9
10
10
In case of semi-wide cap frame, this completes
the working.
