Changing procedure of the frame
1-17
1
In case of TEJTII-C/TEMX-C...................................................................
1. Push the table (4) into the position and fix it using the screw (5).
3. Attaching of border frame
1. Fix the border frame (2) using the screw (1).
4. Attaching of hook cover (In case of TFMX-C)
1. Remove the screw (1) to detach the cap frame guide (2).
Insert the table fitting (6) to the entry of the cover.
4
5
6
1
1
2
In case of TEJTII-C/TEMX-C: Proceed to “Detaching of
cap frame guide” (p.1-18).
You may let the cap frame guide (2) remain as it is.
However, if has a trouble for embroidery works, replace it
with the hook cover (4).
2
1
LX03
