107
MAINTENANCE
Daily Inspection (Every 10 Hours)
1.
Set the machine to the lubrication posture shown in the diagram above, ground the working
equipment, then stop the engine.
2.
Use the grease gun to lubricate the grease nipples.
3.
Wipe off the expelled grease.
