Takeuchi TB125 User Manual

200
OPTIONS
Attachment Combination Table
Below is the bucket combination table for when standard arms, long arms and telescopic
arms are installed.
Heed this table.
WARNING
¡¡
¡¡
¡Consult with a Takeuchi dealer before installing optional attachments.
¡¡
¡¡
¡Do not use attachments that have not been approved by Takeuchi or a Takeuchi
dealer. Doing so may compromise safety or adversely affect the machine’s operation
or service life.
¡¡
¡¡
¡Takeuchi will not be held responsible for any injuries, accidents or damage to
products caused by the use of a non-approved attachment.
¡¡
¡¡
¡TB125
The swing stopper must be mounted when a bucket wider than a 490W bucket is mounted.
¡¡
¡¡
¡TB135
The swing stopper must be mounted when a bucket wider than a 630W bucket is mounted.
Failure to mount the swing stopper may result in the bucket hitting the machine body.
√ : Usable
∆ : Usable for light operations (digging and loading operations with dry, loose or mud)
–: Not usable
Total bucket weight = Weight of bucket + Weight of full bucket load (specific gravity : 1.8)
<TB125>
Bucket
Rated Capacity
m
3
(cu.yd.)
Bucket cutting
width
mm (inch)
Standard Arm
1135 mm (45 in.)
Long Arm
1445 mm (57 in.)
Telescopic Arm
1150 to 1740 mm
(45 to 69 in.)
300W 0.043 (0.056) 300 (11.8)
330W 0.044 (0.058) 330 (13.0)
460W (S.T.D.) 0.068 (0.089) 460 (18.1)
490W 0.075 (0.098) 490 (19.3)
530W 0.084 (0.110) 530 (20.9)
600W 0.104 (0.136) 600 (23.6)
3-Hole Bucket 0.093 (0.121) 460 (18.1)
Total bucket weight = Within 134kg
for Telescopic Arm (295 lb.)
Total bucket weight = Within 263kg
(580 lb.)
Hydraulic Breaker (TKB-101)
√√√
√√√
√√—
√∆—
√∆—
√∆—
√∆—
√√√
√∆—
√√—
Within 600 (23.6)
Within 600 (23.6)
