Takeuchi TB125 User Manual

204
OPTIONS
Long Arm
Operating Ranges (TB125)
4435(174.6) Max. digging height
2890(113.7) Max. digging depth
3175(125) max. dumping height
2205(86.9) Max. vertical digging depth
3325(130.9) Max. vertical digging radius
4725(185.9) Max. ground digging radius
4850(190.9) Max. digging radius
3205(126.1) in Transport position
3425(134.8)
Overrall height; when minimum front slewing
1880(74.1)
1270(50.1)
610(24.0)
540(21.2)
560(22.0)
R1725(68.0)
R1885(74.2)
R1495(59.0)
50(2.0)
Bucket offset
E5L004
Values are indicated in units of mm. inches in ( ).
Front slewing radius
