246
OPTIONS
INSPECTION AND MAINTENANCE
Inspection and maintenance interval
............................ Every 250 hours
Cleaning the Condenser
CAUTION
Cleaning the condenser with high
pressured water may damage it. Clean
the condenser gently.
If the condenser is dirty, heat will not
discharge properly. Wash dirt off the
condenser with water.
1. Open the engine hood.
2. Clean the condenser.
Inspecting and Adjusting
the Air Conditioner Belt
Inspection and maintenance interval
... After first 50 hours (New machines only)
IMPORTANT: Do not let any oil or grease
get on the belt, as it will cause the belt to
slip, shortening its service life and reducing
the air conditioner’s cooling capacity.
If the belt is slack, it will slip and vibrate,
shortening its service life and reducing the
air conditioner’s cooling capacity. The belt
should also not be too tense. Adjust the belt
tension to the standard value (approximately
8 mm or 0.3 in).
Air Conditioner (TB135 / TB145)
< TB135 >
< TB145 >
G4G020
G4L015
2
3
4
1
1
2
3
4
G4L016
K3L0311
2
3
4
1
K3L0321
1
2
3
4
To Next Page
