202
OPTIONS
Middle Arm
Operating Ranges (TB145)
Front slewing radius
795(31.3)
R2005(78.9)
R2190(86.1)
R1705(67.1)
710(28)
715(28.1)
1010(39.7)
4300(169.3)
Overrall height; when minimum front slewing
2185(85.9)
Values are indicated in units of mm, inches in ( ).
Bucket offset
4060(159.8) Max. dumping height
5690(224.1) Max. digging height
4115(161.9)
in Transport position
3650(143.7) Max. digging depth
2885(113.7)
Max. vertical digging depth
3965(156.2)
5855(230.6) Max. ground digging radius
5990(235.9) Max. digging radius
1425(56.1)
Min. dumping height
85(3.3)
