73
OPERA
TION
Machine Operation
Operating the
Auxiliary Hydraulics
Use this to operate a breaker
, crusher or
other attachment.
O
: Open
S
: Closed
When the switch (A) or (B) is pressed,
hydraulic oil is delivered to the auxiliary
hose’
s ports (a) or (b).
a
To
deliver hydraulic oil to port (a):
Press (A).
e
To
deliver hydraulic oil to port (b):
Press (B).
Refer to page 52 “Auxiliary Hydraulic Lines”.
B
A
G4B016
G4D0031
b
a
S
O
74
