213
OPTIONS
Telescopic Arm
Operating Ranges TB135 (Fully Retracted Arm)
G4L008
3880(152.8) Overrall height; when minimum front slewing
2055(80.9)
Front slewing radius
Values are indicated in units of mm, inches in ( ).
Bucket offset
685(27)1330(52.3)
R1910(75.1)
R2065(81.2)
R1650(65)
620(24.4)615(24.1)
65(2.6)
3500(137.8) Max. dumping height
4835(190.4) Max. digging height
3715(146.3) in Transport position
3110(122.5) Max. digging depth
1625(64) Max. vertical digging depth
4225(166.4)
5010(197.2) Max. ground digging radius
5135(202.2) Max. digging radius
