3.32 Privacy Zone Masking Function
Privacy zone masking protects private objects and areas such as house windows,
entrances and exits. Privacy zone masking masks such subjects which are within the
camera’s range of vision, on the monitor.
MP3010M-EV complies with the three-dimension privacy zone masking which enables
to process the mask for Pan/Tilt/Zoom movement by receiving Pan/Tilt/Zoom VISCA
Command.
Data can be set using Commands in CAM_PrivacyZone Command.
Features
1. Mask can be set on up to 8 places according to Pan/Tilt positions.
2. Mask can be displayed on 8 places per screen simultaneously.
3. Individual on/off zone masking settings.
4. Two colors can be individually set for each of 8 privacy zones.
5. Interlocking control with Pan/Tilt/Zoom.
6. Non-interlocking control with Pan/Tilt.
Privacy Zone Mask Command List
Command Set
Command
Command Packet
Comments
H
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
CAM_PrivacyZone
SetMask
8x
01
04
76
0m
0n
0r
0r
0s
0s
FF
Setting Mask(Size)
Parameter: 0m 0n 0r 0r 0s 0s
m: mask number (0h-7h)
n=0: Modify
n=1: New
rr: W
ss: H
Display
8x
01
04
77
0p
0p
0p
0p
FF
Setting Mask Display On/Off
pppp: Mask setting (0: Off, 1: On)
SetMaskColor
8x
01
04
78
0p
0p
0p
0p
qq
rr
FF
Setting Color of Mask
pppp: Mask Color Setting
qq: Color setting when setting the Mask bit to 0
rr: Color setting when setting the Mask bit to 1
SetPanTiltAngle
8x
01
04
79
0p
0p
0p
0q
0q
0q
FF
Setting Pan/Tilt Angle
ppp: Pan angle, qqq: Tilt angle
SetPTZMask
8x
01
04
7B
0m
0p
0p
0p
0q
0q
0q
0r
0r
0r
0r
FF
Setting the direct position of PTZ
m: mask number, ppp: Pan, qqq: Tilt, rrrr: Zoom
Non_InterlockMask
8x
01
04
6F
0m
0p
0p
0q
0q
0r
0r
0s
0s
FF
Setting non-interlocking the mask to pan/tilt
m: mask number, pp: X, qq: Y, rr: W, ss: H
