3.31 Title Display
Data can be set using Commands in CAM_MultiLineTitle Command.
- The title composes of up to 12 lines. Each line can contain up to 20 characters.
- Each line can be individually set to display on/off.
- The top-left X and Y position (every 20 pixels) of title display area and font size (4
sizes) can be set.
Title Display Setting Command List
Command Set
Command
Command Packet
Comments
H
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
CAM_MultiLineTitle
Title Set1
8x
01
04
73
10
00
nn
pp
0q
00
00
00
00
00
00
FF
nn: Title start point X（1 unit = 20 pixel, 00h～7Fh）
pp: Title start point Y（1 unit = 20 pixel, 00h～7Fh）
q: Font size [ 0（smallest） - 3（largest） ]
Title Set2
8x
01
04
73
2L
mm
nn
pp
qq
rr
ss
tt
uu
vv
ww
FF
L: Line Number
mnpqrstuvw: Character Font Number（1 to 10）
Title Set3
8x
01
04
73
3L
mm
nn
pp
qq
rr
ss
tt
uu
vv
ww
FF
L: Line Number
mnpqrstuvw: Character Font Number（11 to 20）
Title Clear
8x
01
04
74
1p
FF
p: 0 to Bh line, p=Fh: all lines
On
8x
01
04
74
2p
FF
p: 0 to Bh line, p=Fh: all lines
Off
8x
01
04
74
3p
FF
p: 0 to Bh line, p=Fh: all lines
Table: Character Code (Font Number)
Font Number
00
01
02
03
04
05
06
07
Character
A
B
C
D
E
F
G
H
Font Number
08
09
0A
0B
0C
0D
0E
0F
Character
I
J
K
L
M
N
O
P
Font Number
10
11
12
13
14
15
16
17
Character
Q
R
S
T
U
V
W
X
Font Number
18
19
1A
1B
1C
1D
1E
1F
Character
Y
Z
&
[space]
?
!
1
2
Font Number
20
21
22
23
24
25
26
27
Character
3
4
5
6
7
8
9
0
Font Number
28
29
2A
2B
2C
2D
2E
2F
Character
a
b
c
d
e
f
g
h
Font Number
30
31
32
33
34
35
36
37
Character
i
j
k
l
m
n
o
p
Font Number
38
39
3A
3B
3C
3D
3E
3F
Character
q
r
s
t
u
v
w
x
Font Number
40
41
42
43
44
45
46
47
Character
y
z
%
[
]
*
+
=
Font Number
48
49
4A
4B
4C
4D
4E
4F
Character
_
"
:
'
.
,
/
-
