5.3.5 LVDS cable specification (reference)
Cable reference specifications (crossover)
 Recommended connectors and cables
Cable: #42 Micro Coaxial cable
ConnectorⒶ: USL20-30S(KEL)
Binding tapeⒷ
 Pin assignment
CN1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
CN2
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
