Tamron MP3010M-EV - Page 34

Tamron Co., Ltd.
34 / 79
48h
LVDS 1080/25p + CVBS PAL
49h
LVDS 720/29.97p + CVBS NTSC(Side cut)
4Ah
LVDS 720/30p + CVBS NTSC(Side cut)
4Bh
LVDS 720/25p + CVBS PAL(Side cut)
4Ch
LVDS 1080/59.94p + CVBS NTSC(Side cut)
4Dh
LVDS 1080/29.97p + CVBS PAL(Side cut)
50h
LVDS+HDMI 1080/30p
51h
LVDS+HDMI 1080/25p
52h
LVDS+HDMI 720/60p
53h
LVDS+HDMI 720/50p
54h
LVDS+HDMI 1080/60p
55h
LVDS+HDMI 1080/50p
56h
LVDS+HDMI 720/59.94p
59h
LVDS+HDMI 720/29.97p
5Ah
LVDS+HDMI 720/30p
5Bh
LVDS+HDMI 720/25p
5Ch
LVDS+HDMI 1080/59.94p
5Dh
LVDS+HDMI 1080/29.97p
LVDS mode
74h
00h(default)
Single
Reflected after
camera reset
01h
Double
Lens Distortion
Compensation
78h
Upper 4bit
0h: Crop, 1h: Complete
Immediate
reflection
Lower 4bit
0h: Off, 1h-4h: Table No.1-4 default: 2h
Maximum
F number
79h
03h
F22
Immediate
reflection
04h
F16
05h
F14
06h(default)
F11
07h
F9.6
08h
F8.0
F Number for Small
Aperture Elimination
7Ah
09h: F6.8, 0Ah: F5.6, 0Bh: F4.8, 0Ch: F4.0(default),
Immediate
reflection
0Dh: F3.4, 0Eh: F2.8, 0Fh: F2.4, 10h: F2.0, 11h: F1.8
Minimum Shutter Speed
7Bh
0Bh: 1/250, 0Ch: 1/350, 0Dh: 1/500, 0Eh: 1/725,
Immediate
reflection
0Fh: 1/1000, 10h: 1/1500, 11h: 1/2000,
12h: 1/3000, 13h: 1/4000, 14h: 1/6000, 15h: 1/10000(default)
Maximum Shutter Speed
7Ch
00h: 1/4(default), 01h: 1, 02h: 1/2, 03h: 1/3, 04h: 1/4,
Immediate
reflection
05h: 1/6, 06h: 1/8, 07h: 1/15 or 1/12.5
Setup Control
7Dh
2Bh
Restore Parameters to factory default
Reflected after
camera reset
