Register Setting
Register Name
Register
No.
Setting value
Reflecting
timing
VISCA Baud Rate
00h
00h(default)
9600 bps
Reflected after
camera reset
01h
19200 bps
02h
38400 bps
03h
115200 bps
Focus detecting area
20h
Start pos=(x1, y1), End pos=(x2, y2)
Immediate
reflection
Focus stop position
21h
10h=Over inf,...,B0h=1.0cm
Immediate
reflection
Opt zoom limit(W-end)
50h
00h(default)
No limit
Reflected after
camera reset
EFh
Max value
Opt zoom limit(T-end)
51h
00h(default)
No limit
Reflected after
camera reset
EFh
Max value
D-Zoom Max
52h
00h
x1
Immediate
reflection
C0h
x4
EAh(Default)
x12
F0h
x16
Zoom Tracking AF
54h
00h
Off
Reflected after
camera reset
01h(default)
On
Keystone Correction
60h
00h=Off(default), 01h=correction low,
..., 12h=correction high
Immediate
reflection
Monitoring Mode
72h
01h(default)
LVDS 1080/30p
Reflected after
camera reset
02h
LVDS 1080/25p
05h
LVDS 720/60p
06h
LVDS 720/50p
07h
LVDS 1080/60p
08h
LVDS 1080/50p
09h
LVDS 720/59.94p
0Bh
CVBS NTSC
0Dh
CVBS PAL
0Eh
LVDS 720/29.97p
0Fh
LVDS 720/30p
11h
LVDS 720/25p
13h
LVDS 1080/59.94p
14h
LVDS 1080/29.97p
1Bh
CVBS NTSC(Side cut)
1Dh
CVBS PAL(Side cut)
30h
HDMI 1080/30p
31h
HDMI 1080/25p
32h
HDMI 720/60p
33h
HDMI 720/50p
34h
HDMI 1080/60p
35h
HDMI 1080/50p
36h
HDMI 720/59.94p
39h
HDMI 720/29.97p
3Ah
HDMI 720/30p
3Bh
HDMI 720/25p
3Ch
HDMI 1080/59.94p
3Dh
HDMI 1080/29.97p
40h
LVDS 1080/30p + CVBS NTSC(Side cut)
41h
LVDS 1080/25p + CVBS PAL(Side cut)
42h
LVDS 720/60p + CVBS NTSC(Side cut)
43h
LVDS 720/50p + CVBS PAL(Side cut)
44h
LVDS 1080/60p + CVBS NTSC(Side cut)
45h
LVDS 1080/50p + CVBS PAL(Side cut)
46h
LVDS 720/59.94p + CVBS NTSC(Side cut)
47h
LVDS 1080/30p + CVBS NTSC
