Initial Value
Factory Default
nn: Title start point X (1 unit = 20 pixel, 00h - 7Fh)
pp: Title start point Y (1 unit = 20 pixel, 00h - 7Fh)
q: Font size [ 0 (smallest) - 3 (largest) ]
L: Line Number
mnpqrstuvw: Character Font Number (1 to 10)
L: Line Number
mnpqrstuvw: Character Font Number (11 to 20)
p: 0 to Bh line, p=Fh: all lines
p: 0 to Bh line, p=Fh: all lines
p: 0 to Bh line, p=Fh: all lines
Setting Mask(Size)
Parameter: 0m 0n 0r 0r 0s 0s
m: mask number (0h-7h)
n=0: Modify
n=1: New
rr: W
ss: H
Setting Mask Display On/Off
pppp: Mask setting (0: Off, 1: On)
Setting Color of Mask
pppp: Mask Color Setting
qq: Color setting when setting the Mask bit to 0
rr: Color setting when setting the Mask bit to 1
Setting Pan/Tilt Angle
ppp: Pan angle, qqq: Tilt angle
Setting the direct position of PTZ
m: mask number, ppp: Pan, qqq: Tilt, rrrr: Zoom
Setting non-interlocking the mask to pan/tilt
m: mask number, pp: X, qq: Y, rr: W, ss: H
Setting CenterLine Display Off
Setting CenterLine Display On
CAM_Continuous
ZoomPosReply
ZoomPosition data Continuous Output On/Off
pp: Interval Time [Vertical timing] (frame count)
addr = 00h: VISCA communication baud rate
pq: 00h=9600bps, 01h=19200bps, 02h=38400bps, 03h=115200bps
addr = 20h: Focus detecting area selection
Start pos = (x1, y1), End pos = (x2, y2).
p: x1, q: y1, r: x2, s: y2 (1 ≤ x1 < x2 ≤ 7, 1 ≤ y1 < y2 ≤ 7)
addr = 21h: Focus stop position
In the case that AF can't find a focusing position
pq: 10h=Over inf, 11h-13h=Linear interpolation between Over inf and Inf,
14h=Inf, 15h-1Fh=Linear interpolation between Inf and 4.7m,
20h=4.7m,21h-2Fh=Linear interpolation between 4.7m and 2.3m,..., B0h=1.0cm
addr = 50h: Opt zoom limit (W-end)
pq: 00h (No limit) - EFh
addr = 51h: Opt zoom limit (T-end)
pq: 00h (No limit) - EFh
addr = 52h: D-Zoom Max
pq: 00h-F0h = DZoomPos / 64 - 256 (ex: 00h=x1, 80h=x2, C0h=x4, E0h=x8, EAh=x12, F0h=x16)
addr = 54h: Zoom tracking
pq: 00h=Off, 01h=On
addr = 60h: Keystone correction
pq: 00h=Off, 01h=correction low, ..., 12h=correction high
pq: 01h=1080/30p, 02h=1080/25p, 05h=720/60p, 06h=720/50p, 07h=1080/60p, 08h=1080/50p,
09h=720/59.94p, 0Bh=NTSC, 0Dh=PAL, 0Eh=720/29.97p, 0Fh=720/30p, 11h=720/25p,
13h=1080/59.94p, 14h=1080/29.97p, 1Bh=NTSC(Side cut), 1Dh=PAL(Side cut)
pq: 30h=1080/30p, 31h=1080/25p, 32h=720/60p, 33h=720/50p, 34h=1080/60p, 35h=1080/50p,
36h=720/59.94p, 39h=720/29.97p, 3A=720/30p, 3Bh=720/25p, 3Ch=1080/59.94p, 3Dh=1080/29.97p
pq: 40h=1080/30p, 41h=1080/25p, 42h=720/60p, 43h=720/50p, 44h=1080/60p, 45h=1080/50p,
46h=720/59.94p, 47h=1080/30p+NTSC(LB), 48h=1080/25p+PAL(LB),
49h=720/29.97p, 4A=720/30p, 4Bh=720/25p, 4Ch=1080/59.94p, 4Dh=1080/29.97p
pq: 50h=1080/30p, 51h=1080/25p, 52h=720/60p, 53h=720/50p, 54h=1080/60p, 55h=1080/50p,
56h=720/59.94p, 59h=720/29.97p, 5A=720/30p, 5Bh=720/25p, 5Ch=1080/59.94p, 5Dh=1080/29.97p
addr = 74h: LVDS mode
pq: 00h=Single, 01h=Double
addr = 78h: Lens distortion compensation
p: 0h: Cropped image, 1h: Complete image
q: 0h=Off, 1h=low Barrel correction only,
2h=Barrel correction only, 3h=Barrel correction and Pincushion correction
addr = 79h: Maximum F number
pq: 03h=F22, 04h=F16, 05h=F14, 06h=F11, 07h=F9.6, 08h=F8.0
addr = 7Ah: F number for Small Aperture Elimination
pq: 09h=F6.8, 0Ah=F5.6, 0Bh=F4.8, 0Ch=F4.0, 0Dh=F3.4, 0Eh=F2.8, 0Fh=F2.4, 10h=F2.0,
11h=F1.8
addr = 7Bh: Minimum Shutter Speed
pq: 0Bh=1/250, 0Ch=1/350, 0Dh=1/500, 0Eh=1/725, 0Fh=1/1000,
10h=1/1500, 11h=1/2000, 12h=1/3000, 13h=1/4000, 14h=1/6000, 15h=1/10000
addr = 7Ch: Maximum Shutter Speed
pq: 00h=1/4, 01h=1/1, 02h=1/2, 03h=1/3, 04h=1/4, 05h=1/6, 06h=1/8, 07h=1/15 or 1/12.5
addr = 7Dh: Setup Control
pq: 2Bh=Restore Parameters to factory default
pp: Chroma Suppress setting level
00h: Off
01h-03h: On (3 levels)
Effect increases as the level number increases.
p: Color Gain Setting 0h (60%) - Eh (200%)
p: Color Hue Setting 0h (-14 degrees) - Eh (+14 degrees)
Lens Temperature Alarm On
Lens Temperature Alarm Off
