33
Model 430
Parts
140425
Model 430 Exploded View Parts Identification List
ITEM DESCRIPTION PART NO.
1 BELT−V−4L350 004194
2 PULLEY−AK49 X 5/8 051394
3 SCREW−5/16−18X5/8 SERR 017326
4 GEAR A.*REDUCER 4.92:1
SERVICE
015985−SER
5 SHELL A.−INSULATED X52574−SER
5a BEARING−REAR SHELL 032511
5b GUIDE−DRIP SEAL 028992
5c NUT−BEARING 028991
5d O−RING−PKG *25 TO BAG*
(1−1/16 OD X .070 WALL)
018432
6 DISC−PROBE *SQ HOLE* 030965
7 PROBE A.−MIX LOW−HT X42077
8 SPACER−PROBE *SQ HOLE* 030966
9 WASHER−#10 EXTERNAL
TOOTH LOCK
002681
10 NUT−10−32 HEX MACHINE
SCREW
005598
11 VALVE−EPR 1/4S 022665
12 PANEL−REAR 049325
13 COVER−CONTROL BOX 049321
14 CONTROL A. (SEE PAGE 35) X50663−
15 VALVE−EXP−AUTO−1/4S X1/4 046365
16 GUIDE A.−DRIP PAN X49327
17 MOTOR−FAN 50 WATT 029770−
18 FAN−5 BLADE 12” PUSH
22DEG CCW
049009
19 SHROUD−FAN 048877
20 CONDENSER−AC 12LX16H 048935
21 PANEL−SIDE L 049639
22 SCREW−10−32X3/8 SLTD 024298
23 DRYER−FILTER 1/4 X 1/4 048878
ITEM DESCRIPTION PART NO.
24 SWITCH A.−TORQUE
(SEE PAGE 37)
X50895−SER
25 SWITCH A.−DRAW
(SEE PAGE 36)
X80870
26 LIGHT−AMBER−RECT−12VDC
ADD MIX
052486−02
27 LIGHT−AMBER−RECT−12VDC
MIX OUT
047142−02
28 PANEL A.−FRONT X50678
29 SWITCH−ROCKER
AUTO/WASH
048420
30 TUBE−CAP..036IDX.087OD X 9 051049
31 PULLEY−AK27−1/2 016190
32 MOTOR−1/4 HP 014477−
33
CORD−POWER−125V−NEMA
5−20P−6’L (115V)
085093
CORD−POWER−230V−15A
PLUG−75”L (208−230V)
025340−27
34 COMPRESSOR
AKA9462ZXA−AK172BT
049302−
35 NUT−5/16−18 FLANGE NUT 017327
36 WASHER−3/8 USS FLAT CR3 000653
37 SLEEVE−MOUNTING−COMP 039920
38 GROMMET−COMPRESSOR
MOUNT
039919
39 SCREW−5/16−18X1−1/2 HEX 001894
40 SUPPORT−DRIP TRAY 049318
41 STUD−NOSE CONE 013496
42 WASHER−FREEZER STUD 049032
43 PROBE A.−MIX OUT−SQ HOLE X41348
44 SWITCH−PRESSURE 440 PSI 048230
*45 PANEL−SIDE R 049640
*NOT SHOWN
