USER INTERFACE
5-7
PH61 Peristaltic Pump
User Interface
5
Screen C is SET CLOCK. This screen will display the
current date and time. The date and time may only be
changed after the machine has been manually

brush-cleaned but before it has been placed in the Auto
mode. Move the cursor under the number you wish to
change. Press the +++ key to increase the number, or
the - - - key to decrease the number.
If an invalid date is entered, a second screen will appear.
When the SEL key is pressed, the previous LCD screen
will appear to allow correction of the entry. The controller
will not advance to the DAYLIGHT SAVING TIME screen
until a valid date is entered.
When a valid date is entered and SEL key is pressed, the
DAYLIGHT SAVING TIME screen will display.
Pressing the arrow keys moves the cursor. Pressing the
SEL key while under DISABLE accepts the selection and
returns to the OPERATOR MENU.
Pressing the SEL key while under ENABLE accepts the
selection and displays the following screen:
To change the default date, move the cursor to NO and
press the SEL key. The following screen will display:
Use the arrow keys to select the desired month and
press the SEL key. The following screen will display:
Use the arrow keys to select the desired month and
press the SEL key. The following screen will display:
SET CLOCK
10:21 AM 11/07/2014
--
<--- ---> +++ --- SEL
SET CLOCK
10:34 AM 02/30/2014
- - INVALID DATE
<--- ---> +++ --- SEL
DAYLIGHT SAVING TIME
ENABLE DISABLE
-------
LES>------<
MAR SECOND SUNDAY
NOV FIRST SUNDAY
YES NO EXIT
___
DST START MONTH
JFMAMJJASOND
MAR
LES>------<
DST START WEEK
1234L
SECOND SUNDAY
LES>------<
DST END MONTH
JFMAMJJASOND
NOV
LES>------<
