Page #63 background imageLoading...
Page #63 background image
Section 9
9-1
PH61 Peristaltic Pump
Parts Replacement Schedule
9
Parts Replacement Schedule
Table 9-1
Part Description Every 3 Months Every 6 Months Annually
Scraper Blade-Shake X
Driveshaft Seal X
Freezer Door O-ring-Shake X
Front Bearing X
Draw Valve O-ring X
Spinner Shaft Seal-Shake X
Pivot Pin O-ring X
Restrictor Cap-Shake X
Mix Feed Tube O-ring X
Pump O-ring X
Mix Inlet Tube O-ring X
Mix Feed Tube Check Ring X
Air Inlet Fitting Seal X
Pump Driveshaft O-ring X
Pump Valve Gasket X
White Bristle Brush, 3” x 7” Inspect and replace if
necessary.
Minimum
Peristaltic Pump Tubes Inspect and replace if
necessary.
Minimum
White Bristle Brush, 1-1/2” x 2” Inspect and replace if
necessary.
Minimum
White Bristle Brush, 1” x 2” Inspect and replace if
necessary.
Minimum
Black Bristle Brush, 1” x 2” Inspect and replace if
necessary.
Minimum
Double-Ended Brush Inspect and replace if
necessary.
Minimum
Door-spout Brush Inspect and replace if
necessary.
Minimum
Brush Set (3) Inspect and replace if
necessary.
Minimum
