TB-Electronics F-SCAN COMPACT - OPTION DIRP: Operating Procedure; DIRP Operating Procedure

- 32 -
The segmented handhold must be
placed in the right hand such, that
the forefinger curls around the
DIRP sensor w ithout pressure.
Both hands should be kept as
steady as possible during the DIRP
run to avoid false readings.
Operating procedure
1. Connect handholds,
Sw itch device ON
2. Select
INDIVIDUAL A PPLIC.
Display shows program
position ‚1’
Use UP- or DOWN- keys to select the program
position to store the DIRP results in
3. Place the handholds in both hands
as pictured and described above. A
sticky pad electrode may be used
in lieu of the steel handhold on the
red cable.
4. Press the RIGHT-key.
o After selecting DIRP with KEY_RIGHT, a selection menu opens:
 KEY_CENTER = START normal.
 KEY_F2 = start FAST mode.
 KEY_LEFT = EXIT.
