Technical Specifications
VL3X – Reference manual (updated 2015-07-16) 190
CONNECTIONS
ANALOG INPUTS
Voice
Connector Combo Balanced XLR/Balanced TRS 1/4“ phone jack
Input Impedance Balanced 3.08 kOhm
Mic Input Level @ 0 dBFS -52 dBu to +7 dBu
Line Input Level @0dBFS -40 dBu to +19 dBu
EIN @ Max Mic Gain Rg = 150 Ohm -127 dBu
Mic SNR >100 dB at typical Mic Input gain
Phantom Power +48V (on/off via setup menu)
A to D Conversion 24 Bit, 128 x oversampling bitstream, 110 dB SNR A-weighted
Guitar
Connector 1/4“ phone jack
Guitar Input Impedance 1 MOhm
Guitar Input Level @ 0 dBFS -2 dBU to 14 dBu
Guitar Input SNR >108 dB
A to D Conversion 24 Bit, 128 x oversampling bitstream, 110 dB SNR A-weighted
Monitor
Connector Balanced XLR
Input Impedance Balanced 25 kOhm
Monitor Input Level @ 0 dBFS +16 d Bu
Aux
Aux 1/8“ stereo mini jack
Aux Input Level @ 0 dBFS +2 dBu
ANALOG OUTPUTS
Voice
Connectors Balanced XLR
Output Impedance Balanced/Unbalanced 300/150 Ohm
Output Range 0 dBFS Line Level: +14 dBu; Mic Level: -2dBu
Dynamic Range >109 dB, 20 Hz to 20 kHz
Frequency Response +0/-0.3 dB, 20 Hz to 20 kHz
D to A Conversion 24 Bit, 128 x oversampling bitstream, 115 dB SNR A-weighted
Guitar
Connectors 1/4“ TRS phone jack
Output Impedance Balanced/Unbalanced 442/221 Ohm
Output Range 0 dBFS Line Level: +14 dBu; Mic Level: -2dBu
Dynamic Range >105 dB, 20 Hz to 20 kHz note
