TC-Helicon VL3X User Manual

Setup
VL3X – Reference manual (updated 2015-07-16) 157
Output tab
XLR Output Mode parameter
Use the XLR Output Mode parameter to select
the output mode for VL3X.
Parameter settings:
► Stereo:
► The left XLR output jack carries the left ste-
reo channel.
► The right XLR output jack carries the right
stereo channel.
► Mono:
► The left XLR output jack carries the summed
(with effects) mono vocal & guitar channel
signals.
► The right XLR output jack carries the mono
vocal signal without effects.
► The dry channel includes Tone and Au-
to-Chromatic Pitch Correction (if applica-
ble).
► The dry channel does not contain HardTune
effect(s).
► Dual Mono:
► The left XLR output jack carries the summed
(with effects) mono vocal channel.
► The right XLR output jack carries the
summed (with effects) mono guitar channel.
XLR Output Level parameter
Use the XLR Output Level parameter to set the
relative level of the signal going to the XLR out-
puts.
Parameter settings:
► Mic Level: Typically the best setting when
connecting to a mixer/PA. This level closely
replicates that of a microphone going directly
into the mixer.
► Line Level: When connecting to a mixer/PA
line inputs, this setting is a good choice.
More information about mixing
and configuring outputs properly
► For a tutorial on PA basics, Yorkville has an
extremely useful “PA Primer” guide (PDF):
yorkville.com/downloads/other/basicpaprim-
er.pdf
► There is also a great “Craig’s Corner” video
episode covering Mixer Setup with TC-Heli-
con devices:
youtube.com/watch?v=qq0AOtafIjs
► And another with tips on eliminating feedback:
youtube.com/watch?v=VlN1RJ4gcAo
