Introduction
VL3X – Reference manual (updated 2015-07-16) 20
For more information, see “Loop button param-
eters”.
Mix knobs
From the Home screen, turn-
ing any mix knob enters the
Mix screens (Main, Head-
phones and Effects).
For more information on the Mix screens, see
“Using the Mix Controls”.
Within an Edit page, the mix knobs adjust pa-
rameter settings. Each mix knob controls the pa-
rameter shown right above it in the display.
Arrow buttons
When you are on the Home
screen, you can use the Ar-
row buttons to move through
Presets.
When you are on an Edit screen, use the Arrow
buttons to move between tabs.
NP LED
The NP LED lights when Nat-
uralPlay (chord) information
is received via Guitar, MIDI,
Aux, Looper or RoomSense.
Level LEDs
Read the level LEDs as follows:
► If you play your guitar with-
out singing, the LEDs show
your guitar level.
► If you sing and don’t play
guitar, the LEDs show your
vocal level.
► If you play and sing, the LEDs show a com-
bined level.
