TC-Helicon VL3X User Manual

Introduction
VL3X – Reference manual (updated 2015-07-16) 28
Inputs
VL3X inputs overview
1. DC Power connector
2. XLR and ¼” Combo jack input
3. ¼” Guitar input
4. 1/8” Stereo Aux and XLR Monitor input jacks.
Please note that Aux input and Monitor input
are mutually exclusive. Only one may be used
at a time.
5. MIDI Input
6. Footswitch. Connect a TC-Helicon Switch-3
or Switch-6 here. You can also connect a
second expression pedal here – see “Working
with a second expression pedal”.
7. Expression pedal input
8. USB Host port
