27
83503001 Rev G
AC Input Range AC Input Cable
190-240V~, Single Phase
3 x 12AWG (2 wire plus safety ground)), stranded copper, 300V,
60°C minimum, rated for 25A. 3m max. length, outer diameter:
9~11mm.
190-240V~, Three Phase
4 x 14AWG (3 wire plus safety ground), stranded copper, 300V,
60°C minimum, rated for 15A. 3m max. length, outer diameter:
9~11mm.
380-415V~, Three Phase
4 x 16AWG (3 wire plus safety ground), stranded copper, 600V,
60°C minimum, rated for 10A. 3m max. length, outer diameter:
9~11mm.
Table 1-2: Recommended AC input cable
