7.11.3. Service Request: Enable and Event Registers
The conditional Registers are continuously monitored. When a change is detected in a
register bit which is enabled, the power supply will generate an SRQ message.
The SRQ message is: “Inn” terminated by CR, where the nn is the power supply
address. The SRQ will be generated either in Local or Remote mode.
Refer to Tables 7-9 to 7-12 for details of the Enable and Event registers.
7.11.3.1. Fault Enable Register
The Fault Enable Register is set to the enable faults SRQs.
Table 7-9: Fault Enable Register (FENA nn, FENA?)
BIT
Enable
bit name
Fault symbol Bit Set condition Bit reset condition
0 (LSB) Spare bit SPARE
1 AC Fail AC
2 Over Temperature OTP
3 Foldback FOLD
4 Over Voltage OVP
5 Shut Off SO
6 Output Off OFF
7(MSB) Enable ENA
User command:
“FENA nn” where nn
is hexadecimal
User command: “FENA
nn” where nn is
hexadecimal (if nn=”00”,
no fault SRQs will be
generated).
7.11.3.2. Fault Event Register
The Fault Event will set a bit if a condition occurs and it is Enabled. The register
is cleared when FEVE?, CLS or RST commands are received.
Table 7-10: Fault Event Register (FEVE?)
BIT
Enable
bit name
Fault symbol Bit Set condition Bit reset condition
0 (LSB) Spare bit SPARE
1 AC Fail AC
2 Over Temperature OTP
3 Foldback FOLD
4 Over Voltage OVP
5 Shut Off SO
6 Output Off OFF
7(MSB) Enable ENA
Fault condition occurs
and it is enabled.
The fault can set a
bit, but when the fault
clears the bit remains
set.
Entire Event Register is
cleared when user sends
“FEVE?” command to
read the register.
“CLS” and power-up also
clear the Fault Event
Register. (The Fault Event
Register is not cleared by
RST)
