32
83503001 Rev G
3. INSTALLATION
3.1. General
This Chapter contains instructions for initial inspection, preparation for use and
repackaging for shipment. Connection to PC, setting the communication port and linking
Genesys™ power supplies are described in Chapter 7.
WARNING
The Genesys
TM
series is intended only for installation in Restricted
Access Location (RAL). Access to Hazardous parts (rear side of the
power supply) shall be prevented after installation.
NOTE
Genesys
TM
power supplies generate magnetic fields, which might affect the
operation of other instruments. If your equipment is susceptible to magnetic fields,
do not position it adjacent to the power supply.
WARNING
To avoid electric shock hazard, do not insert conductive parts through
the front panel slits.
3.2. Preparation for Use
In order to be operational the power supply must be connected to an appropriate AC
source. The AC source voltage should be within the power supply specification. Do not
apply power before reading Section 3.3, 3.6 and 3.7.
Table 3-1 below, describes the basic setup procedure. Follow the instructions in Table 3-1
in the sequence given to prepare the power supply for use.
Step no. Item Description Reference
1 Inspection Initial physical inspection of the power supply Section 3.3
2 Installation
Installing the power supply, Ensuring adequate
ventilation.
Section 3.4
Section 3.5
3 AC source
AC source requirements
Connecting the power supply to the AC source
Section 3.6
Section 3.7
4 Test Turn-on checkout procedure. Section 3.8
5 Load connection
Wire size selection. Local/Remote sensing. Single or
multiple loads.
Section 3.9
6 Default setting The power supply setting at shipment. Section 7.2.1
Table 3-1: Basic Setup Procedure
