80
83503001 Rev G
Table 7-3: Voltage Programming Range Table 7-4: Current Programming Range
Model
Rated Output Voltage (V)
Minimum
(V)
Maxi
(V)
Model Mini
(A)
Maxi
(A)
8 0.000 8.000 GEN8-400 000.00 400.00
10
00.000 10.000 GEN10-330 000.00
330.00
15 00.000 15.000 GEN15-220 000.00 220.00
20 00.000 20.000 GEN20-165 00.00 165.00
30 00.000 30.000 GEN30-110 00.00 110.00
40 00.000 40.000 GEN40-85 00.00 85.00
60 00.000 60.000 GEN60-55 00.000 55.000
80 00.00 80.000 GEN80-42 00.000 42.000
100 000.00 100.00 GEN100-33 00.000 33.000
150 000.00 150.00 GEN150-22 00.000 22.000
300 000.00 300.00 GEN300-11 0.000 11.000
600 000.00 660.00 GEN600-5.5 0.000 5.500
Table 7-5: OVP Programming Range Table 7-6: UVL programming range
Model
Rated Output Voltage (V)
Mini
(V)
Maxi
(V)
Model
Rated Output Voltage (V)
Mini
(V)
Maxi
(V)
8 0.5 10.0 8 0 7.60
10 0.5 12.0 10 0 9.50
15 1.0 18.0 15 0 14.3
20 1.0 24.0 20 0 19.0
30 2.0 36.0 30 0 28.5
40 2.0 44.0 40 0 38.0
60 5.0 66.0 60 0 57.0
80 5.0 88.0 80 0 76.0
100 5.0 110.0 100 0 95.0
150 5.0 165.0 150 0 142
300 5.0 330.0 300 0 285
600 5.0 660.0 600 0 570
NOTE
The power supply can accept values higher 5% than the table values, however it
is not recommended to program the power supply over the rated values.
7.9. Fast Queries
These are commands that read a response very quickly from the power supply. They use
unprintable character codes. They allow the power supply to avoid the normal command
processing delays.
The processing time for these queries is typically 2 mSec, so total query speed is 2 mSec
plus the RS-232/485 transmission time.
Since these queries embed the power supply address (0 to 30), there is no need to first
send the “ADR n” addressing command.
7.9.1. Fast Test for Connection
This is an addressed query that is good for scanning to see what supplies are “on line”.
If no response is returned within 10 mSec, your control program has determined that no
power supply is connected at that address.
