83503001 Rev G
c) For any command that sets a numeric value, the value may be up to 12 characters
long.
d) Carriage Return: If the CR character (ASCII 13) is received by itself, the power
supply will respond with “OK” and CR.
7.7.2. Command Set Categories
The Genesys™3300W series command set is divided into four categories as follows:
1) Initialization control
2) ID control
3) Output control
4) Status control
7.7.3. Initialization Control Commands
# Command Description
1 ADR n
ADR is followed by address, which can be 0 to 30 and is used to access the power supply.
2 CLS
Clear status. Sets FEVE and SEVE registers to zero (refer to Section 7-11).
3 RST
Reset command. Brings the power supply to a safe and known state:
Output voltage: zero, Remote: non-lockout remote,
Output current: zero, Auto-start: Off,
Output: Off, OVP: maximum,
FOLD: Off, UVL: zero
The conditional registers (FLT and STAT) are updated, the other registers are not changed.
4 RMT
Sets the power supply to local or remote mode:
1. RMT 0 or RMT LOC, sets the power supply into Local mode.
2. RMT 1 or RMT REM, sets the unit into remote mode.
3. RMT 2 or RMT LLO, sets the unit into Local Lockout mode (latched remote mode).
5 RMT?
Returns to the Remote mode setting:
1. “LOC” - The unit is in Local mode.
2. “REM” - The unit is in Remote mode.
3. “LLO” - The unit is in Local Lockout (latched remote) mode.
6 MDAV?
Returns if Multi-drop is installed. 1 indicates installed and 0 indicates not installed.
7 \
Repeat last command. If \<CR> is received, the power supply will repeat the last command.
7.7.4. ID Control Commands
#
Command Description
1 IDN? Returns the power supply model identification as an ASCII string:LAMBDA, GENX-Y
2 REV? Returns the software version as an ASCII string.
3 SN? Returns the unit serial number. Up to 12 characters.
4 DATE? Returns date of last test. Date format: yyyy/mm/dd
7.7.5. Output Control Commands
# Command Description
1 PV n
Sets the output voltage value in Volts. The range of voltage value is described in Table 7-3. The
maximum number of characters is 12. See the following examples for PV n format: PV 12, PV
012, PV 12.0, PV 012.00, etc…
2 PV?
Reads the output voltage setting. Returns the string “n” where “n” is the exact string sent in the
PV n command. When in Local mode, returns the PREVIEW (front panel) settings in a 5 digit
string.
3 MV?
Reads the actual output voltage. Returns a 5 digits string.
Example: 60V supply sends 01.150, 15.012, 50.000, etc…
4
PC n
Set the Output Current value in Amperes. The range of current values is described in Table 7.4.
The maximum number of characters is 12. See the following examples for PC n format: PC n
format: PC 10, PC 10.0, PC 010.00, etc…See Note 1
5 PC?
Reads the Output Current setting. Returns the string “n” where “n” is the exact string sent in the
PC n command. When in Local mode, returns the PREVIEW (front panel) settings in a 5 digit
string.
6 MC?
Reads the actual Output Current. Returns a 5 digit string.
Example: 200A supply sends 000.50, 110.12, 200.00, etc…See Note 2
