*1: Minimum voltage is guaranteed to maximum 0.2% of the rated output voltage.
*2: Minimum current is guaranteed to maximum 0.4% of the rated output current.
*3: For cases where conformance to various safety standards (UL, IEC etc.) is required, to be
described as 190~240Vac (50/60Hz).
*4: A ith rated output power.
*5: Not including EMI filter inrush current, less than 0.2mSec.
*6: At 170~265Vac, constant load.
*7: From No-load to Full-load, constant input voltage. Measured at the sensing point in Remote
Sense.
*8: For 8V~300V models: measured with JEITA RC-9131A (1:1) probe.
For 600V model: measured with 10:1probe.
*9: From10% to 90% or 90% to 10% of rated output voltage, with rated , resistive load.
*10: From 90% to 10% of rated output voltage.
*11: For load voltage change, equal to the unit voltage rating, constant input voltage.
*12: For 8V~16V models the ripple is measured at 2V rated output voltage and rated output
current. For other models, the ripple is measured at 10~100% of rated output voltage and
rated output current.
*13: The Constant Current programming readback and monitoring accuracy does not include the
warm-up and Load regulation thermal drift.
*14: Measured withJEITA RC-9131A (1:1) probe.
*15: Measured at the sensing point.
The supplemental characteristics give typical but non-warranted performance characteristics. The supplemental
characteristics are useful in assessing applications for the power supply. Several kinds of supplemental characteristics are
listed below.
1.Evaluation Data: Typical performance of the power supply.
2.Reliability Data: Reliability performance of the power supply.
3.EN61000 Data: Performance of the power supply under EN61000 test conditions.
4.EMI Data: Typical EMI (conducted and radiated) performance of the power supply.
NOTES:
2.12 SUPPLEMENTAL CHARACTERISTICS
t 200Vac input voltage, w
Models with Vout 50V: Output is SELV, all communication/control interfaces: RS232/485, IEEE,
Isolated Analog,LAN, Sense, Remote Programming and Monitoring, 5V d.c. auxiliary output are
SELV.
Models with 60V Vout 400V: Output is Hazardous, communication/control interfaces:
RS232/485, IEEE,Isolated Analog, LAN, Remote Programing and Monitoring (pins 1-3, pins14-
16), 5V d.c. auxiliary output are SELV, Sense, Remote Programming and Monitoring (pins 8-
13, pins 21-25),15V auxiliary output are Hazardous.
Models with 400V Vout 600V: Output is Hazardous, all communication/control interfaces-
RS232/485, IEEE, Isolated Analog, LAN, Sense, Remote Programming and Monitoring (all
pins), 5V d.c./15V d.c. auxiliary outputs are Hazardous.
2.11 SAFETY/EMC
2.Interface classification
4.Insulation resistance
More than 100Mohm at 25 C, 70%RH.
O
Vout 50V models:
Input-Output/communication/control/auxiliary outputs (SELV): 4242VDC 1min,
Input-Ground: 2828VDC 1min., Output/communication/control/auxiliary outputs (SELV)-Ground:
1000VDC 1min.
60V Vout 100V models:
Input-Output/15V d.c. auxiliary output/communication/control (Hazardous): 2600VDC 1min,
Input-communication/control/5V d.c. auxiliary output (SELV): 4242VDC 1min,
Output/15V d.c. auxiliary output/communication/control (Hazardous): -
communication/control/5V d.c. auxiliary output (SELV): 1900VDC 1min,
Output/15V d.c. auxiliary output/communication/control (Hazardous): -Ground: 1200VDC 1min,
Input-Ground: 2828VDC 1min.
100V Vout 600V models:
Input-Output/15V d.c. auxiliary output/communication/control (Hazardous): 4000VDC 1min,
Input-communication/control/5V d.c. auxiliary output (SELV): 4242VDC 1min,
Output/15V d.c. auxiliary output/communication/control (Hazardous): -communication/control/
5V d.c. auxiliary output (SELV): 3550VDC 1min,
Output/15V d.c. auxiliary output/communication/control (Hazardous): -Ground: 2670VDC 1min,
Input-Ground: 2828VDC 1min.
3.Withstand voltage
1.Applicable standards:
EMC
Safety
UL 60950-1, CSA22.2 No.60950-1, IEC 60950-1, EN 60950-1
EN55022, EN55024, EN61000-3-3, FCC part 15, VCCI.
Conducted emmision - EN55022 class A, FCC part 15 class A, VCCI class A.
Radiated emmision - EN55022 class A, FCC part 15 class A, VCCI class A.
Immunity - EN55024
12
