CHAPTER 7 RS232&RS485 REMOTE CONTROL
7.1INTRODUCTION
7.2 CONFIGURATION
Thischapter describes the operationofthe Genesys 2400W power supplies via theserial
communication port. Details of theinitialset-up, operation via RS232 or RS485, thecommand set
and thecommunicationprotocol are described in this chapter.
The power supplyisshipped with th efollowing setting:
TM
7.2.1 Default setting
-Address:
-Baud-rate:
-RS232/485:
-Vout setting:
-Iout setting:
-Master/Slave
6
9600
RS232
0
Maximum
H1 (Master)
-Output:
-Start up mode:
-OVP:
-UVL:
-Foldback:
-Front panel:
Off
Safestart
Maximum
0
Off
Unlocked (UFP)
7.2.2 Address setting
7.2.3 RS232 or RS485 selection
7.2.4 Baud rate setting
7.2.5 Settingthe unitinto Remoteor Local mode
The power supply addresscan be set to any address between0and 30. Follow the instructions
described below to setthe address.
1. If the unitisin Remote mode (front panel REM/LOC LED illuminates), press REM/LOC
buttonto put the unitinto Local mode.
2. Press and holdfor approximately3sec. the REM/LOC button. The VOLTAGE displaywill
indicate thecommunication port address.
3. Usingthe VOLTAGE adjust encoder, select the address.
To previewthe addressat any time, press and holdthe REM/LOCbutton for approx. 3sec. The
VOLTAGE displaywill indicate the power supply address.
To select between RS232 or RS485 setthe rear panel setup switch SW1-6 position to:
- Down for RS232
-Upfor RS485
Five optional ratesare possible: 1200, 2400, 4800, 9600 and 19200. To select thedesiredrate,
thefollowing steps should be taken:
1. If the unitisin Remote mode (front panel REM/LOC LED illuminates), press REM/LOC
buttonto put the unitinto Local mode.
2. Press and holdfor approx.3sec. the REM/LOC button. The CURRENT display will show
thecommunicationport Baud Rate.
3. Usingthe CURRENT adjust encoder,selectthe desired Baud Rate.
1. The unitwill be
put into Remote mode only via serial communication command.
Commands that will put the unitinto Remote mode are:
RST PV n
OUT nPCn
RMT n
(fornvalues seeTables 7-3, 7-4, 7-5 and 7-6)
