TDK-Lambda Genesys GEN8-300 - Outline Drawings

13
2.13 GENESYS 2400W POWERSUPPLIES
OUTLINE DRAWINGS
TM
482.8+/-1.0mm
43.6+/-0.3mm
A
AA
603.0+/-1.0mm
57.8+/-0.5
92.0+/-0.5
92.0+/-0.5
21.0
440.8+/-1.0mm
422.8+/-1.0mm
Note 1
Note 1
Note 4
Note 2 (150V~600V)
Note 2
Note 5
NOTES:
1.Mating plug supplied with power supply.
2.Bus-bars for 8V to 100V models. See detail.
Wire clamp connector for 150V to 600V models (shown).
3. AC cable strain relief (supplied with power supply).
4. Chassis slides: GENERAL DEVICES P/N: CC3001-00-S160
or equivalent, mounting holes #10-32 marked "A".
5. Bus Bars enclosure for 60V to 600V.
104+/-2.0mm
Note 3
39.5+0.5mm
22.0mm
3.0mm
30.0mm
Bus-Bar Detail
8V to 100V Models
8.5mm
T
D
L
a
m
b
d
a
-
I
T
D
L
amb
d
a
-
I
0-8V 0-300A
GEN8-300
