TDK-Lambda Genesys GEN8-300 - Setting up the Power Supply for 0-5;0-10 V Isolated Programming and Monitoring; Setting up the Power Supply for 4-20 Ma Isolated Programming and Monitoring; Setup and Operating Instructions

65
SW1 position 3 and4must be in their Up position for
operation with 4-20mA Isolated Programming and
Monitoring.
To prevent damage to the unit, do not program
the output voltage and current to higher then the
power supply rating.
Perform the following procedure to configure the power supply:
1. Turn the power supply AC power switch to Off.
2. Connect a short between J1-8 and J1-12 (refer to Table 4-4).
3. Set Setup switch SW1-1 to itsUP position for Output Voltage external programming
and SW1-2 to itsUP position for Output Current limit external programming.
4. Set SW1 position 3to select the programming voltage range: Down=0-5V, Up=0-10V.
5. Set SW1 position 4to select the monitoring range: Down=0-5V,Up=0-10V.
6. Ensure that SW1 positions 7 and 8 are in the their down position.
7. Connect the programming sources to the mating plug of the Isolated Programming
connector.Observe for correct polarity of the voltage source.
8. Set the programming sources to the desired levels and turn the power supply ON.
Perform the following procedure to configure the power supply:
1. Turn the power supplyAC power switch to Off.
2. Connect a short between J1-8 and J1-12 (refer to Table 4-4).
3.Set setup switch SW1-1 to itsUP position for Output Voltage external programming and
SW1-2 to itsUP position for Output Current limit external programming.
4. Set SW1 position 3to it's Up position.
5. Set SW1 position 4to it's Up position.
6. Ensure that SW1 positions 7 and 8 are in their Down position.
7. Connect the programming source to the mating plug of the Isolated Programming
connector.Observe for correct polarity of the voltage source.
8. Set the programming sources to the desired levels and turn the power supply ON.
8.4.2 Setting up the power supply for 4-20mA Isolated Programming and Monitoring
8.4.1 Setting up the power supply for 0-5/0-10V Isolated Programming and Monitoring
8.4 SETUP AND OPERATINGINSTRUCTIONS
J1-8 and J1-12 must be shorted together withajumper.
J1-8 and J1-12 must be shorted together withajumper.
CAUTION
VORSICHT
HINWEIS
HINWEIS
HINWEIS
NOTE
NOTE
NOTE
Um das Gerät vor Schäden zu schützen,
programmieren Sie keine Spannungs- oder
Stromwerte, die über den maximalen
Nennwerten liegen.
Für die isolierte Programmierung und Überwachung
mittels 4-20mA-Signalen müssen die Schalter 3 und 4
von SW1 in der oberen Position stehen.
J-8 und J-2müssen über einen Jumper miteinander
verbunden werden.
111
J-8 und J-2müssen über einen Jumper miteinander
verbunden werden.
111
