Installing the CD-RW Drive
8TEAC CD-RW Drive User’s Manual
Installing the CD-RW Drive
1. Turn off the power to the computer system and any external devices
connected to it.
2. Touch the exposed metal frame of the computer to ground yourself.
This will prevent damage to the computer and the CD-RW drive that may be
caused by a discharge of static electricity.
3. Remove your computer’s cover, faceplate, or 5.25-inch bay cover, as well
as mounting clips, screws, and retaining brackets.
4. If you have a SCSI CD-ROM drive installed in your system, or if you do
not
have an IDE CD-ROM/DVD drive installed in your system, do the
following:
4a)
Confirm that the jumper on the rear panel of the CD-RW drive is
configured to its default setting of Master.
4b)
Slide the CD-RW drive into an empty 5.25" drive bay. Install the CD-RW
drive in your computer in a horizontal or vertical orientation (within ±5˚
of horizontal or vertical). The Eject button should be located on the right
side of the unit. Secure the drive using the included 3x5mm mounting
screws.
Note:
TEAC recommends that you connect the CD-RW to the secondary IDE port.
Do not connect the drive in a “daisy-chain” to the hard disk drive.
Note:
If you have a SCSI CD-ROM drive—or if you do not have an IDE CD-
ROM/DVD drive—installed in your system, please continue with Step 4. If you
have an IDE CD-ROM/DVD drive installed in your system, please skip step 4 and
continue with Step 5.
Warning:
Do not use mounting screws longer than the included 3x5mm
screws to secure the CD-RW drive or you may damage the unit.
