28 TEAC CD-RW Drive User’s Manual
Appendix B. Specifications
The following table lists the product specifications for the TEAC CD-RW drive.
Model CD-W552E
Interface IDE/ATAPI
Transfer Rate Write: 52X maximum (7.8MBps)
Rewrite: 24X maximum (3.6MBps)
Read: 52X maximum (7.8MBps)
Access Time 100 msec (1/3 Stroke)
Audio Extraction Speed 52X maximum (7.8MBps)
Video Playback 52X maximum (7.8MBps)
Buffer Size 2MB
Buffer Management Buffer underrun prevention
Write Methods Track At Once; Disk At Once; Session At Once; Packet Write
Write Verification Running Optimum Power Control to dynamically adjust laser
write power
Logical Recording
Format
IS09660, UDF & CDR-FS Packet Write
Read Compatibility CD-DA; CD-ROM Mode-1; CD-ROM XA Mode-2 (Form-1 and
2); Multi-session PhotoCD; CD-I; Video CD; CD Plus; CD-RW;
CD-R; CD-TEXT
Disc Loading Power Tray (caddy not required)
Front Panel Built-in Headphone Jack, Dual Status LEDs, Volume Control
Knob, and Power Eject Button
MTBF 100,000 POH
Dimensions 5.86”(W) x 1.63”(H) x 7.78”(D)
Weight 2.2 lbs.
Power Supplies +5VDC, +12VDC
Analog Audio
Headphone
Line-Out
0.7Vrms
0.7Vrms
Headphone Jack 3.5mm diameter stereo mini-headphone jack
Installation Horizontal or vertical, plus or minus 5°
Operating Temperature 5° C to 45° C (41° F to 113° F)
Storage Temperature -20° C to 60° C (-4° F to 140° F)
Operating Humidity 20% to 80% (non-condensing)
Storage Humidity 15% to 85% (non-condensing)
Agency Certificate UL, CSA, TUV, FCC, FDA
