System Connections (Continued)
Connecting External AV Device (AV Output)
Use the AV cables to connect external AV device to the audio and video output jacks on the jack
panel of the unit to output TV、Composite or S-VIDEO signals.
After connection, turn on the unit and external AV device and press the SOURCE button to shift to
corresponding mode.
Connecting DVB-T Antenna
Use the DVB-T antenna to connect the DVB-T input Jacks on the rear panel of the unit to the
external AV signal source. After connection, turn on the unit and external DVB-T device and press
the SOURCE button to shift to DVB mode.
