11. PROGRAMMING PROCEDURES
11.10 SPEED KEY SETTING
11-17
11.10 SPEED KEY SETTING
Menu Page: 1
Item No.: 9
The SL-9000 has a maximum of 70×2 speed keys which are very convenient to call PLUs quickly.
(Refer to page 5-3 regarding the Key Layout.)
■ Setting Department/Vendor Number
● Department Number
When initial set #10-6 is set to 1, the six-digit PLU # is divided into two; the upper two digits are assigned to department #, and the lower
four digits to PLU.
The department # is automatically added in the front of the four-digit PLU # and treated as a six-digit PLU #.
In case of PROG., Report, and Reset modes, PLU # is treated as a six-digit number. So the upper two digits are not treated
as department #. Consequently the four-digit PLU # is available only in REG., M.DOWN, and REWRAP modes.
NOTE: The default Dept No. is a two- digit serial number ranging from o to 99. Entering a 0 clears a Dept. No.
● Vendor Number
Vendor numbers can be be set when the Initial Setting #11-1 is set to 1.
Vendor numbers are assigned to the speed keys in two ways:
① Individual vendor number: 00-39
Vendor # is assigned to the speed keys one by one.
② Group vendor number: 0-, 1-, 2- and 3-
Maximum 10 vendor numbers can be assigned to one speed key, resulting in 4 speed keys in total. When assigning group vendor
numbers to the speed keys, enter the first digit of the vendor key (0, 1, 2 or 3) plus a bar (-).
Vendor numbres can be called whichever half of the speed keys are selected.
9
<MENU>
Page 1
Enter the Speed
Key number
(# 1
〜
70 on each page)
ENTER
PROG.
ESC.
<MENU>
Page 1
Main
<MENU>
i
i
Enter the PLU#.
(max. 6 dig.)
ENTER
NEXT
PLU
or
Toggles the speed
key Page
◇
9
<MENU>
Page 1
PROG.
ESC.
<MENU>
Page 1
Main
<MENU>
ENTER
AUTO
CODE
Enter the speed
key number.
Enter the default
department #. (1〜99)
Enter the department #
or vendor #. (1
〜
99)
ENTER
◇
ENTER
Selecting items to be assigned
to speed keys.
(PLU #/VENDOR #/DEPT #/)
