Each listing in the tune table will need all the required fields entered.
Figure 101 below is an entry along with a description of what each field contains.
192.168.3.54 0 9 8.1 192.168.6.2 35
192.168.3.54 = IP address of the tuner to be set.
0 = Tuner index. There are 2 tuners per IP address, so this is either 0 or 1.
9 = Actual RF channel number of the broadcasting station.
8.1 = Virtual channel number and program stream desired.
192.168.6.2 = IP Address of the QAM to output the tuned channel.
35 = Port number of the QAM corresponding to the desired QAM channel which will carry the
tuned ATSC channel.
Once you have developed a tune table which will work in your area with the appropriate data
entered for each of the tuners you need in your system, press the SAVE button, then the RUN
button to make this active on the ATSC-8. You should see this change immediately if properly
connected to a QAM.
Figure 101 - ATSC Tune Table
