AInstallation
C
Ref. DCD01/3074 - XF510Cr-Sr-Dr_en_C
20/31
Approximative forces exerted on the part to mark
Efforts exerted on the part
The axial effort of the stylus on the part depends on the stylus type and on the operating pressure.
The lateral efforts transmitted via the stylus on the part to mark depend on the material.
For typical steels, lateral effort in X-Y is equal to the axial effort.
These values are used to dimension the clamping of the part in relation with the desired safety coefficient.
Stylus
NA0 NA1 NA1 LG 100 N2 NA2
Fx = Fy (daN) ± 8.0 ± 18.8 ± 18.8 ± 36.9 ± 36.9
Fz (daN) -8.0 -18.8 -18.8 -36.9 -36.9
Pressure (Bar)
12345678
Stylus to be used Force (daN)
NA0 1.3 2.7 4.0 5.3 6.6 8.0 9.3 10.6
NA1 - NA1 LG 100 3.1 6.3 9.4 12.6 15.7 18.8 22.0
N2 - NA2 6.2 12.3 18.5 24.6 30.8
Poor clamping may allow the part to move and the stylus point to break.
