A
Ref. DCD01/3074 - XF510Cr-Sr-Dr_en_C
3/31
AIntroduction
1. Unpacking
Depending on the order, the machine is packed on its own or with a Control Unit.
Contents of the box:
• machine: XF510Cr/Sr/Dr
• 1 test plate for the machine
• 1 technical document on CD ROM
If ordering a pack:
• Control Unit: UC500
• power cable
• 1 air filter
Additional accessories if ordered:
• 1 CCU/Marking head connecting cord
• 1 (or several) styli
• 1 RS232 connecting cable
• marking program + 1 CD-ROM with user manual
2. Identification of the marking equipment
The marking equipment is identified by:
• 1 identification plate on the marking head
• 1 identification plate on the Control Unit
Have the model and serial number of the equipment available when contacting Technifor.
3. Power
• power supply: 115 V AC - 230 V AC - 50/60 Hz
• power: 120 VA
• compressed air supply: operating pressure: 1 Bar (14.504 PSI) to 8 Bar (116.03 PSI)
• pneumatic cylindrical female connection 1/4
" gas
4. Regulation observance
Manufacturer, GravoTech Marking SAS - 56 avenue Jean Jaurès BP 80015 - 10604 LA CHAPELLE SAINT LUC -
France (head office) declares:
Declaration of compliance
CE marking on the equipment attests the observance of the following European directives:
• Directive 2006/95/EC of the European Parliament and of the Council of 12 December 2006 on the
harmonisation of the laws of the Member States relating to electrical equipment designed for use within certain
voltage limits.
• Directive 2004/108/EC of the European Parliament and of the Council of 15 December 2004 on the
harmonisation of the laws of the Member States relating to electromagnetic compatibility.
