AOperating instructions for the machine
B
Ref. DCD01/3074 - XF510Cr-Sr-Dr_en_C
8/31
2. Technical specifications
• NA0 - NA1 - NA1 LG 100 - N2 - NA2 scribing styli
Note: these values are approximative. They may vary slightly depending on the part’s material.
• Fonts available:
- continuous action (standard)
- dot by dot (optional)
- size: from 0.5 mm (0.02 in) to 44.9 mm (1.768 in) with increments of 0.1 mm (5/1000 in)
- characters: those included in the basic multilingual diagram of the Unicode standard (ISO 10646)
Note: the small character sizes are incompatible with the bigger styli.
• Dates, counters, batch numbers, shift codes, logos...
3. Physical characteristics
Pressure (Bar)
Stylus to be used 12345678
NA0 No Yes Yes Yes Yes Yes Yes Yes
NA1 - NA1 LG 100 Yes Yes Yes Yes Yes Yes Yes No
N2 - NA2 Yes Yes Yes Yes Yes No No No
XF510Cr XF510Sr XF510Dr
Length 182 mm (7.165 in) 222 mm (8.74 in) 302 mm (11.89 in)
Width 167 mm (6.575 in) 167 mm (6.575 in) 167 mm (6.575 in)
Height 224 mm (8.819 in) 224 mm (8.819 in) 224 mm (8.819 in)
Weight 9 kg (19.842 lb) 10 kg (22.046 lb) 11.5 kg (25.353 lb)
Marking area 40 mm (1.575 in)
x 50 mm (1.969 in)
80 mm (3.15 in)
x 50 mm (1.969 in)
160 mm (6.299 in)
x 50 mm (1.969 in)
