Ref. DCD01/3074 - XF510Cr-Sr-Dr_en_C

26/31

EWearing and spare parts

Please give the item codes with your order to speed processing.

1. Wearing parts

Standard styli

• point only

• repair kit stylus (seal + spring + washer)

The scribing stylus points cannot be sharpened.

Styli:

Repair kits:

Reference Description

Ref.: 53034 Carbide scribing stylus NA02 110° with radius 0.2 mm (0.008 in)

Ref.: 53035 Diamond scribing stylus NDA02 110° with radius 0.2 mm (0.008 in)

Ref.: 53036 Carbide scribing stylus NA07 110° with radius 0.7 mm (0.028 in)

Ref.: 53039 Carbide scribing stylus NA12 110° with radius 0.2 mm (0.008 in)

Ref.: 53038 Scribing stylus NA12 110° LG 100 mm (3.937 in) carbide with radius 0.2 mm (0.008 in)

Ref.: 53040 Diamond scribing stylus NDA12 110° with radius 0.2 mm (0.008 in)

Ref.: 53037 Carbide scribing stylus NA17 110° with radius 0.7 mm (0.028 in)

Ref.: 53032 Carbide scribing stylus N22 110° with radius 0.2 mm (0.008 in)

Ref.: 53033 Diamond scribing stylus ND22 110° with radius 0.2 mm (0.008 in)

Ref.: 56073 Carbide scribing stylus NA22 110° with radius 0.2 mm (0.008 in)

Reference Description

Ref.: 57989 Repair kit (o-ring /spring) for NA0 stylus

Ref.: 57482 Repair kit (o-ring /spring) for NA1 stylus

Ref.: 55876 Repair kit (o-ring /spring) for N2-NA22 stylus
