TechniSat DIGITRADIO 30 User Manual

73
DE
EN
FR
NL
5.3.3 Using headphones
Hearing impairment!
Do not listen to the radio at high volume with headphones.
Doing so can cause permanent hearing impairment. Turn
down the radio volume to the lowest volume before using
headphones.
Only use headphones with a 3.5 mm jack plug.
> Insert the headphone plug into the headphone
jack on the rear of the device. Sound will now only
be heard via the headphones, and the speaker is
switched to mute.
> If you would like to use the speakers again, unplug
the headphones from the headphone jack on the
radio.
5.4 General device functions
5.4.1 Switching on the device
To ensure good DAB+ / FM reception, please note
Section 5.3.2.
> First prepare the DIGITRADIO 30 for operation as
described in Section 5.3.
> Push the On / Standby buon on the top of the
unit to turn on the DIGITRADIO 30.

TechniSat DIGITRADIO 30 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	20
Number of built-in speakers	1
Package type	Box
Package depth	80 mm
Package width	275 mm
Package height	170 mm
Package weight	840 g
Power source	AC/Battery
AC input voltage	230 V
DC input voltage	3.7 V
AC input frequency	50 Hz
Projection	No
MP3 playback	-
Product color	Gray
Volume control	Rotary
On Screen Display (OSD) languages	DEU, ENG, FRE, ITA
International Protection (IP) code	IPX5
Operating temperature (T-T)	-20 - 60 °C
Headphone connectivity	3.5mm / Bluetooth
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB charging voltage	5 V
RMS rated power	2 W
Battery life	15 h
Battery type	Built-in battery
Battery capacity	3000 mAh
Bluetooth profiles	A2DP, AVRCP

Weight and Dimensions

Depth	47 mm
Width	136 mm
Height	162 mm
Weight	478 g
