TechniSat DIGITRADIO 30 User Manual

95
DE
EN
FR
NL
14 Troubleshooting
If the device does not operate as intended, check the
following table for information.
Symptom Possible cause/remedy
The device cannot be
switched on.
The device is not being
supplied with power. Connect
the power supply unit correctly
to the socket and to the device.
Charge the rechargeable
baery.
No sound can be
heard.
Increase the volume.
Poor reception via
DAB+/FM.
Change the position of the
DIGITRADIO 30.
Bad Bluetooth
connection and
dropouts
Do not exceed the maximum
range for Bluetooth of 10m.
If the malfunction has not been resolved, even aer
performing the checks described, please contact the
Technical Hotline, see Section 3.2.4 on page 67.

TechniSat DIGITRADIO 30 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	20
Number of built-in speakers	1
Package type	Box
Package depth	80 mm
Package width	275 mm
Package height	170 mm
Package weight	840 g
Power source	AC/Battery
AC input voltage	230 V
DC input voltage	3.7 V
AC input frequency	50 Hz
Projection	No
MP3 playback	-
Product color	Gray
Volume control	Rotary
On Screen Display (OSD) languages	DEU, ENG, FRE, ITA
International Protection (IP) code	IPX5
Operating temperature (T-T)	-20 - 60 °C
Headphone connectivity	3.5mm / Bluetooth
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB charging voltage	5 V
RMS rated power	2 W
Battery life	15 h
Battery type	Built-in battery
Battery capacity	3000 mAh
Bluetooth profiles	A2DP, AVRCP

Weight and Dimensions

Depth	47 mm
Width	136 mm
Height	162 mm
Weight	478 g
